Wrap Around Labeler Model Tru-Labeler-W1

ACASI Tru-Labeler-W1

Wrap Around Labeler Model Tru-Labeler-W1

Wrap Around Labeler Model Tru-Labeler-W1

Main Construction Features:

  • 1500 in/min labeling head
  • Maximum label height: 7.25in
  • Heavy duty 304 stainless steel frame
  • Heavy duty casters standard
  • No change parts needed for a wide range of containers
  • Stepper driven
  • Labeling head for wraparound labels placed on round containers
  • Rolls wind #4
  • Maximum container width: 6”
  • Minimum container height: 1/2”
  • Conveyor: 10ft long, 4.5” wide acetal chain with speed control installed on labeler control panel

Electric and pneumatic requirements:

  • 208 – 240 Volts, Single phase, 50/60Hz, 10 Amps.
